Bobrick 1080/1180 Series Bathroom Stalls
Best fitted to heavily used buildings with huge traffic and wet areas. DuraLineSeries come with an amazing black edge ensuring a polished edge and the longest durability. Offer varieties of colors, woodgrains, and a long-range of finishes. Get 25 years of warranty.
- Mavi New York
- Bobrick DuraLineSeries® CGL Toilet Partitions
Privacy First
Get unlimited privacy in the most affordable budget. In Washington State, Vashon Island High School has become very popular for having an all-gender restroom on the campus. Bobrick DuraLineSeries fulfill all the demand of the modern school restroom having the maximum height, gap-free and heavy duty toilet partitions. The full-height brackets of these bathroom dividers achieve durability and privacy extensively fulfilling the demand of today’s school restrooms.
Bobrick DuraLineSeries CGL at a glance
- Model
- 1080 series (Class A fire-rated 1180 series also offered)
- Construction
- Solid compact grade laminate (CGL) with black phenolic-resin core and polished black edges
- Thickness
- Stiles and doors 3/4"; panels and urinal screens 1/2"
- Standard size
- 58" door and panel height, 12" floor clearance
- Maximum size
- 71 3/4" with 4 1/2" clearance; extended heights 73" to 96" with 1" clearance
- Mounting
- Floor-anchored, overhead-braced, floor-to-ceiling, ceiling-hung
- Privacy
- Standard reduced-gap, or interlocking gap-free option
- Fire rating
- ASTM E84 Class B (1080), Class A (1180)
- Warranty
- 25-year limited on panels, doors and stiles; 1 year on hardware and brackets
Specifications as published by Bobrick: Bobrick DuraLineSeries CGL, Bobrick 1080 technical data. Final sizes, colors and options are confirmed in your Mavi New York quote.
Usage
DuraLineSeries CGL toilet dividers are best convenient to projects desiring long-lasting results with minutely optimized performance, such as:
- Schools and universities
- Mass transit
- Office space
- Industrial facilities
- School Spotlight
Pollak Library is a great real-life example of a beneficiary that got extensive flexibility using DuraLineSeries CGL. The gap-free, maximum height partition feature ensured privacy dramatically and helped to build a controversy-free all-gender restroom.
Bobrick 1080/1180 Series Bathroom Stalls Best fitted to heavily used buildings with huge traffic and wet areas. DuraLineSeries come with an amazing black edge ensuring a polished edge and the longest durability. Offer varieties of colors, woodgrains, and a long-range of finishes. Get 25 years of warranty. Mavi New York Bobrick DuraLineSeries® CGL Toilet Partitions Privacy First Get unlimited privacy in the most affordable budget. In Washington State, Vashon Island High School has become very popular for having an all-gender restroom on the campus. Bobrick DuraLineSeries fulfill all the demand of the modern school restroom having the maximum height, gap-free and heavy duty toilet partitions. The full-height brackets of these bathroom dividers achieve durability and privacy extensively fulfilling the demand of today’s school restrooms. Bobrick DuraLineSeries CGL features & benefits
- Fully graffiti resistant, moisture and scratch protected
- Budget-friendly
- Freedom of color & pattern selection
- Completely anodized aluminum framing system
- Overhead-braced
- Sightlines is completely eliminated to ensure the privacy
- ASTM E84 Class A or B Standard Fire Rating
- Huge customization facility based on the building’s needs
- 3/4" CGL stiles & doors including 1/2″ panels
Hardware Options
Built-in stainless steel hardware features in DuraLineSeries CGL, meet the projects’ demand completely. Fully anodized aluminum fittings and Bobrick’s standard Traditional Partitions secures all the modern functions smoothly.
Stainless steel hinges ensure a super flexible door closure system
Latch, keeper & brackets are made of stainless steel
Lead Time & Pricing
Price ranges from $ to $$$$$. The following pricing and delivery time are only applicable to standard color choices.
- DuraLineSeries CGL
- Price Range: $$
- Lead Time: 8 days
Bobrick DuraLineSeries® CGL Toilet Partitions specifications
Our partitions and cubicles are ready-to-buy products. To get more details about the ordering procedures utilize the links provided. These will help you with a DIY customization option enhancing the opportunity to get a more personalized design.
ASTM E 84 Fire Rating
| Option | Model Number |
|---|---|
| Class A* | 1180 Series |
| Class B | 1080 Series |
ASTM E 84 Technical Bulletin
Partition Materials’ TB-73 Burning Characteristics of Surface >
*10-day program may exclude Class A Fire-Rated 1180 Series.
Height Details
Heavy customization option of our DuraLineSeries CGL helps to minimize the gap or make you enable to eliminate the sightlines or gaps completely in some cases. Download the Brochure >
| Type | Door & Panel Heights | Floor Clearance | Model Number Class B/A |
|---|---|---|---|
| Standard | 58″ | 12″ | 1080/1180 |
| Maximum | 72″ | 4 ⁵/₁₆″ | 2080/2180 |
| Extended* | 84″ to 96″ | 1″ | 3080/3180 |
Gaps
| Option | Features | Model Number |
|---|---|---|
| Standard Reduced-Gap | Hinge or Keeper gaps: ± 3/32″ Wall gaps: 1/2″ to 1″ | 1080/1180 or 2080/2180 |
| Gap-Free Doors & Stiles | Interlocking, sightline-free design | Add G suffix to 1080/1180 or 2080/2180 |
Hardware
DuraLineSeries’s standard concealed stainless steel hardware package includes barrel hinges, latch and keeper, bracket, coat hook, inswing door hardware and/or outswing door pull. Optimize your design with the options below.
- Full height steel brackets ensure heavy duty. Add suffix ranging from.67 to 2080/2180 or 1080/1180.
- Occupancy Indicator Latch provides extended privacy. The part number is 1002612.
- Peep No More™ automatic indicator sign provides great occupancy. Click to Download >
Mounting Types
| Construction Style | Model Number Class B / A |
|---|---|
| Floor Mounted | 1081 (Std. Ht.) 2081 (Max. Ht.) |
| Headrail Braced | 1082 (Std. Ht.) 2082 (Max. Ht.) |
| Floor to Ceiling | 1086 (Std. Ht.) 2086 (Max. Ht.) |
| Ceiling Hung | 1088 (Std. Ht.) 2088 (Max. Ht.) |
Floor Mounted
Headrail Braced Floor Mounted
Floor to Ceiling
Ceiling Hung
Colors, Woodgrains and Patterns
DuraLineSeries® CGL bathroom partitions are available in a variety of colors, textures, and woodgrains. Choose from the patterns you love.
ABET LAMINATI and FUNDERMAX provide the standard color option with a width of 72”. These eliminate the additional use of any hardware. Serve with Class A fire rating without any additional charge. *Wilsonart® SOLICOR™ is a special laminate that comes with a solid color core to have a great surface match. Premium is applicable for a color upcharge.
Download Compact Grade Laminate Color Guide
Urinal Dividers & Urinal Screens
DuraLineSeries urinal screens and urinal dividers are available with varieties of mounting styles. You may reference to the model number below during the specification.
| Construction Style | Shower Dividers Class B/A | Dressing Part Class B/A | Urinal Dividers Class B/A |
|---|---|---|---|
| Headrail Braced | 1082/1182 | 1082/1182 | – |
| Floor to Ceiling | – | – | 1081/1181 |
| Post-to-Ceiling | – | – | 1083/1183 |
| Wall-Hung | – | – | 1085/1185 |
| Ceiling-Hung | – | – | 1088/1188 |
Dressing compartments with headrail braced features can be decorated with shower curtains, hooks, and curtain tracks. These all are concealed in the headrail.
Get the freedom of matching your dressing compartments and urinal screens with selected toilet partitions. Solid color composite is regarded as the best selection to deal with wet areas.
From takeoff to delivery of Bobrick 1080/1180 Series Bathroom Stalls Best fitted to heavily used buildings with huge traffic and wet areas. DuraLineSeries come with an amazing black edge ensuring a polished edge and the longest durability. Offer varieties of colors, woodgrains, and a long-range of finishes. Get 25 years of warranty. Mavi New York Bobrick DuraLineSeries® CGL Toilet Partitions Privacy First Get unlimited privacy in the most affordable budget. In Washington State, Vashon Island High School has become very popular for having an all-gender restroom on the campus. Bobrick DuraLineSeries fulfill all the demand of the modern school restroom having the maximum height, gap-free and heavy duty toilet partitions. The full-height brackets of these bathroom dividers achieve durability and privacy extensively fulfilling the demand of today’s school restrooms. Bobrick DuraLineSeries CGL to your site
- Call or send plansCall 718-874-3805, or send drawings, a room list or the spec section for Bobrick DuraLineSeries CGL.
- Specialist takeoffOur toilet partition estimator counts stalls, urinal screens and hardware, confirms mounting, ADA layout and colors, and returns a priced quote.
- Order and deliveryWe place the order with Bobrick and arrange delivery to your site. Installation is available across NY, NJ and CT.
