Euro Style Bathroom Partitions
Bradley Loft Series
Bradley Loft Series Toilet Partitions are regarded as one of the finest European-style bathroom partitions. These bathroom partitions are ideal for any type of restroom design. Their outstanding design and seamless construction eliminate the gaps, providing a no-sightline solution. Frameless construction unlocks a fresh look without the hardware visible.
Bradley Euro Style Loft Series at a glance
- Construction
- 3 mm phenolic faces over a moisture-resistant foam core with aluminum edge framing; frameless look, no visible hardware
- Thickness
- Panels, doors and pilasters 1.4" (36 mm)
- Height
- 81.9" including 4" floor clearance; 9" above-floor option for ADA stalls
- Hinges
- Integral 110 degree slow-close hinge with finger protection on in-swing doors; 180 degree barrel hinge on out-swing doors
- Hardware
- Stainless knob with paddle and emergency release, coat hook, door bumper, continuous U-brackets
- Colors
- 7 standard colors plus custom
- Ratings
- ADA, ASTM D6578, ASTM D2794, ASTM E84 Class B
- Mounting
- Overhead braced; privacy and urinal screens available
- Warranty
- 5 years against delamination
Specifications as published by Bradley: Bradley Loft Series, Loft datasheet, CSI spec 102113.17. Final sizes, colors and options are confirmed in your Mavi New York quote.
| Feature / Category | Specifications & Details |
|---|---|
| Product Overview | Bradley Loft Series Euro Style Partitions are frameless, modern, minimalist commercial partitions manufactured by Bradley Corporation. |
| Panel Material | Exclusive Phenolic LT material, which is impact and scratch-resistant, non-porous, and features an anti-bacterial coating to reduce the spread of germs. |
| Construction & Core | "Sandwich-type" construction utilizing either a moisture-resistant honeycomb cardboard or foam core to prevent delamination. |
| Face Sheets | Solid grade phenolic face sheets measuring 0.1-inch (3 mm) or 1/8-inch thick on both sides of the core. |
| Edge Banding | Seamlessly encased in an extruded aluminum profile edge banding. |
| Overall Thickness | Doors, panels, and pilasters all measure 1.4 inches (36 mm) thick. |
| Standard Height | 81.9 inches (2080 mm) total height, which includes the floor clearance. |
| Floor Clearance | Standard models feature a 3.9-inch (100 mm) clearance, with an optional 9-inch (229 mm) clearance available for accessible or ambulatory stalls. |
| Available Colors | Graphite, Dark Walnut, Birch, White, Peppered White, Light Gray, and Aluminum (custom colors are also available). |
| Hardware (In-Swing) | Equipped with maintenance-free, hidden 110° pivot slow-close gravity hinges that include built-in finger protection. |
| Hardware (Out-Swing) | Equipped with exposed 180° self-closing barrel hinges (does not include finger protection). |
| Lock & Latch System | Stainless steel door knob featuring an easy-to-use interior paddle, a white/red occupancy indicator on the outside, and an emergency release hole that can be unlocked using a 4 mm (5/32 inch) Allen key. |
| Smart Features (Optional) | LED Occupancy Indicator integrated directly into the pilasters (illuminates green when empty, red when in use), which requires a hardwired 12VDC transformer. |
| Mounting & Framing | Overhead-braced design utilizing continuous aluminum "U" brackets for wall connections, and a flush 1.2-inch (30 mm) aluminum headrail cap across the top of the doors and pilasters. |
| Available Configurations | Toilet enclosures, floor-anchored privacy screens, and wall-hung or floor-supported urinal screens. |
| Warranty | Backed by a 5-year manufacturer's warranty specifically protecting against material delamination. |
Long-lasting with a wonderful appearance
Outstanding design makes cleaning easier
Flush surface mounting style
No-frame construction hides the hardware
Lightweight and easy to install
110° pivot slow-close hinge
Phenolic LT material
No maintenance required
Technical Information & 3-Part Specs
Color Options (Phenolic Core)
Product Literature
Brochures and selection guides for architects, contractors and facility teams.
Corporate Interiors BrochureDownload
Material Selection Guide – Glass & Phenolic LTDownload
Euro Style Partitions BrochureDownload
Corporate Interiors Brochure (french / Spanish)Request a copy
Warranty Information
We provide warranty for every partition we sell. The effectiveness of the warranty will continue if the purchase of the partition goes with our terms and conditions. We ensure one year of warranty. The repair or replacement of the defective toilet partition units will be the liability of Mavi New York with this warranty. But Mavi New York will not be liable for consequential, incidental, or indirect damage caused by the purchaser. Our warranty extends to institutional and commercial purchasers.
- 15 YearsPowder Coated Steel Partitionsagainst rust-out
- 15 YearsStainless Steel Partitionsagainst rust-out
- 15 YearsBradmar Solid Plastic Partitions
- 3 YearsPlastic Laminate Partitionsagainst delamination and discoloration
- 3 YearsPhenolic Partitionsagainst delamination and discoloration
- 15 YearsFusion Granite Partition Panels and Pilasters
- 5 YearsBradley Euro Style Partitions (Phenolic LT and Glass)
- 5 YearsChrome Plated Zamac Hardware
- LifetimeStainless Steel Hardwareof the partition
This warranty does not cover installation labor charges and does not apply to any units that have been damaged by accident, abuse, improper installation, improper maintenance, or altered in any way. The replacement or repair of defective partitions units as stated in this warranty shall constitute the sole remedy of the purchaser and the sole liability of Mavi New York under this warranty.
MAVI NEW YORK SHALL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES CAUSED BY DEFECTS IN PARTITION UNITS OR ANY DELAY IN THE REPAIR OR REPLACEMENT THEREOF.
Gallery of Applications
How to Install Video
From takeoff to delivery of Euro Style Bathroom PartitionsBradley Loft Series Bradley Loft Series Toilet Partitions are regarded as one of the finest European-style bathroom partitions. These bathroom partitions are ideal for any type of restroom design. Their outstanding design and seamless construction eliminate the gaps, providing a no-sightline solution. Frameless construction unlocks a fresh look without the hardware visible. Bradley Euro Style Loft Series to your site
- Call or send plansCall 718-874-3805, or send drawings, a room list or the spec section for Bradley Euro Style Loft Series.
- Specialist takeoffOur toilet partition estimator counts stalls, urinal screens and hardware, confirms mounting, ADA layout and colors, and returns a priced quote.
- Order and deliveryWe place the order with Bradley and arrange delivery to your site. Installation is available across NY, NJ and CT.
